Deepstor
User Instructions
ISSUE 1
User Instruction
AUGUST 2003
Page 4
GLOSSARY OF DEXION TERMINOLOGY
The following terms are referred to within this guide.
Rack/Block:
The complete structure, in length, depth and height, consisting all lanes and
levels from the front of the rack to the back.
Lane:
A proportion of the rack separated by support frames includes all levels in
the height.
Level:
An individual storage level within a lane. Could be either at floor level or at
a raised level where the pallets are stored on pallet rails.
Pallet Rails:
Horizontal supports either side of a lane to support pallets at raised levels.
Support Arms:
Cantilever brackets that attach to the rack uprights to support the beam rail.
Bracing:
Fitted within selected lanes at the top, rear and lane sides to provide the
structure with necessary stability.
Stop the truck:
The expression “stop the truck” means that the drive is neutralised and the
brake is applied.
Drive slowly:
The expression “drive slowly” means travelling at a speed not exceeding
2.5km/h.
FLT
Fork Lift Truck
FLT Clearance:
Clearance between Support Arm / Rail and the widest part of the forklift
truck (i.e. mast or driver cab).
