8
d. ACA
Range Resolution Accuracy Overload Protection
40µA 0.1µA ±0.8% of reading, Fuse*
400µA 0.001mA ±3 digits F600V, 2A, 31CM
40mA 0.01mA
400mA 0.1mA
2A 0.001A
10A 0.01A ± 3% of reading, ± 7 digits Fuse* F600V, 10A, 31CM
e. OHM (Resistance,
Ω)
Range Resolution Accuracy Overload Protection
400
Ω
0.1
Ω
±0. 75% of reading, 600V DC or
4k
Ω
0.001k
Ω
±3 digits AC Peak
40k Ω 0.01k Ω
400k
Ω
0.1k
Ω
4M
Ω
0.001M
Ω
40M Ω 0.01M Ω ±1% of reading, ±3 digits
f. Diode Test
Test Voltage Max Test Current Over Load Protection
3V Approx. 1mA 600 V DC or Peak AC
g. Continuity Buzzer
Test Voltage Threshold Over Load Protection
3V <100
Ω
600 V DC or Peak AC
h. Capacitance
Range Resolution Accuracy Overload Protection
400µF 0.01µF ±2% of reading, ±3 digits 600V DC or
20000µF 0.1µF ±3% of reading, ±5 digits Peak AC
i. General Specifications
Power Supply 9 Volt Battery
Battery Life 560 hrs. Alkaline
Size (H x L x W) 33mm x 86mm x 187mm
(1.3” x 3.4” x 7.4”)
Weight 340g (12 oz)
3. Specifications
IEC 1010 Over Voltage:
CAT II - 1000V
CAT III - 600V
Pollution Degree 2
a. DCV
Range Resolution Accuracy Impedance
400mV 0.1mV ±0.5% of reading, 10M Ω
4V 0.001V ±2 digits
40V 0.01V
400V 0.1V
1000V 1V
b. ACV (60Hz to 400Hz)
Range Resolution Accuracy Impedance
400mV 0.1mV ±0.8% of reading, 10M Ω
±3 digits
4V 0.001V
40V 0.01V
400V 0.1V
750V 1V
c. DCA
Range Resolution Accuracy Overload
Protection
40µA 0.1µA ±0.5% of reading, Fuse*
400µA 0.001mA ±3 digits F600V, 2A, 31CM
40mA 0.01mA
400mA 0.1mA
2A 0.1mA
10A 0.01A ±1.2% of reading, Fuse*
±3 digit F600V, 10A, 31CM
9
*Warning: Use only correct size, voltage and current rated fuses.
Test Leads: Use only correct type and overvoltage category rating. *Warning: Use only correct size, voltage and current rated fuses.
Test Leads: Use only correct type and overvoltage category rating.
