Model TLA-50 Tube Leveling Amplifier 9
Applications
Basic In-line Connection of the TLA-50
Input Output
Channel
Input
TLA-50 MIC PREAMP
Mixer
OUTPUTS CLASS A -TUBE LEVELER MODEL TLA-50
SUMMIT AUDIO INC. CARMEL, CA USA
115V 50/60 HZ
100V 50/60 HZ
INPUT +4 BAL. -10 UNBAL. LINK INSERT
SIDE
CHAIN
+4 BAL. -10 UNBAL.
20
WATTS
MAX
FUSE
PUSH
OUTPUTS CLASS A -TUBE PREAMP MODEL
SUMMIT AUDIO INC. CARMEL, CA USA
115V 50/60 HZ
100V 50/60 HZ
INPUT +4 BAL. -10 UNBAL. +4 BAL. -10 UNBAL.
20
WATTS
MAX
FUSE
PUSH
Inline Connection
