PARTS LIST
REMOTE-READY MODELS
This list contains replaceable
parts used in your fireplace.
When ordering parts, follow the
instructions listed under Re-
placement Parts on page 33 of
this manual.
PARTS LIST
Remote-Ready Models:
VMH26PRA, VMH26NRA, EFS26PR, EFS26NR, FMH26PR and FMH26NR
** Part not available for field replacement.
PART NUMBERS
VMH26PRA VMH26NRA
KEY EFS26PR EFS26NR
NO. FMH26PR FMH26NR DESCRIPTION QTY.
1 102633-02 102633-02 Outer Casing Top 1
2 102624-02 102624-02 Outer Casing 1
3 099230-02 099230-02 Shoulder Screw 14
4 098304-01 098304-01 Screw, #10 x 3/8" 17
5 107178-02 107178-01 Burner 1
6 103209-01 103209-01 Louvered Door 1
7 102635-02CK 102635-02CK Left and Right Side Front 2
8 103209-01 103209-01 Brass Top Louver 1
9 104281-02BR 104281-02BR Firebox Hood 1
10 102638-01 102638-01 Firebox Top 1
11 103778-01 103779-01 ODS/Pilot Assembly 1
12 ** ** Firebox Wrapper 1
13 104322-01 104322-01 Burner Tube 1
14 104335-01CK 104335-01CK Outer Shell Base 1
15 102649-02 102649-02 Branch Support 1
16 102445-01 102445-01 Piezo Ignitor 1
17 — 099918-02 Regulator, Pilot 1
18 098271-10 098271-10 Ignitor Cable 1
19 107186-01 107186-02 Injector 1
20 M11084-26 M11084-26 Screw, Hex Head, #10 x 3/8" 25
21 098249-01 098249-01 Nut, M5 6
22 103781-02 103781-01 Gas Valve 1
23 102639-01 102639-01 Baffle 1
24 101628-01 101628-01 Flexible Connector 1
25 104305-01 104305-01 Control Shield 1
26 103295-03BR 103295-03BR Screen Assembly 1
27 107153-01 107153-01 Log Set Assembly Kit 1
28 104313-01 104313-01 Right Hinge 1
29 104313-02 104313-02 Left Hinge 1
30 M10908-2 M10908-2 Hinge Screws 4
31 103734-01 103734-01 Burner Support 2
32 101006-02 101006-02 Pilot Bracket 1
33 097809-02 097809-02 Connector, Male 1
34 101629-01 101629-01 Bushing 1
35 101629-02 101629-02 Bushing 1
36 M12461-26 M12461-26 Gas Valve Screws 4
37 103587-02CK 103587-02CK Plate, Switch 1
38 099998-01 099998-01 Switch, Fan 1
39 098264-02 098264-02 Connector, Male 1
40 103284-03 103284-03 Wire Harness 1
41 — 099387-14 Pilot Tube to Regulator 1
42 099387-13 099387-15 Pilot Tube to Control Valve 1
PARTS AVAILABLE — NOT SHOWN
103877-01 103877-01 Lighting Instructions Plate 1
100563-01 100563-01 Warning Plate 1
103470-02 103470-02 Hardware Package 1
