Important: You can use an AC (220/240 V) Output Module (cat. no. 1771sc-
OMI16) to drive terminals on the 1771sc-IMI16, as shown in Figure 3. Use the
same AC power source to power both modules to ensure proper phasing
and prevent module damage. (Note: the 1771sc-OMI16 is an isolated output
module.)
Figure 3
Driving an Input with an Output
6
Installation Data
AC/DC (220/240 V) Input Module
Cat. No. 1771sc-IMI16
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
L1
AC high
L2
AC low
220 VAC
Supply
AC/DC (220/240 V)
Isolated Input Module
(Cat. No. 1771sc-IMI16)
AC (220/240 V)
Isolated Output Module
(Cat. No. 1771sc-OMI16)
