section thr
ee
6
Mounting
Your transmitter may rest flat on a horizontal surface, or it may be wall-
mounted. To mount on a wall, insert two screws (provided) 2" apart in a
horizontal line, leaving the screw heads approximately 1/4" from the wall.
Slip the two holes located on the bottom of the transmitter over the
screw heads and gently slide the unit down until it locks into place. (See
figure 3.)
Note: The screws that came with your Signal Repeater may be fastened to wallboard or
wood with an ordinary Phillips screwdriver; no pre-drilling is necessary. To fasten into
concrete, hollow or grout filled block, brick, or plaster, pre-drill a 3/16" hole and fasten
with an ordinary Phillips screwdriver.
Figure 3.
2"
