BATTERY RESISTANCE METER
The user can check battery's total resistance, the highest resistance, the lowest
resistance and each cell's resistance.
Please connect the battery to the charger main battery lead to battery socket and
balance wires to balance socket.
Press the START/ENTER to enter the Lithium Battery
Resistance program.
The screen indicate each cell's resistance.
The screen indicate the total resistance, the highest
resistance and the lowest resistance.
Start
Enter
B A T T / P R O G R A M
B A T T R E S I S T A N C E
0 1 2 0 0 5 0 0 5 mΩ
0 0 6 mΩ
T A T A L : 2 8 mΩ
H : 1 2 mΩ L : 5 mΩ
19 · B6 mini
INC
This diagram shows
the correct way to
connect your battery to
check the resistance.
Battery
Pack
0 0 5 0 0 3 0 0 3 mΩ
0 0 5 mΩ
