E4
CONTRO L LOC A TIONS
1. Handle
2. CDG LED
3. PLAY/PAUSE LED
4. LED
11. PLAY/PAUSE button
10. ON/OFF button
FRON T VIEW
25. CD Door
24. MIC 2 Jack
13. SKIP button
12. STOP button
5. REPEAT LED
6. PROGRAM LED
7. Disco Light
8. Disco Light ON/OFF button
9. ON/OFF LED
22. ECHO Control
23. MIC Volume Control
14. SKIP button
15. PROGRAM button
16. REPEAT button
17. MIC 1 Jack
18. Loudspeaker
19. Auto Voice Control
20. Master Volume Control
21. BALANCE Control
