380 D Digital to Analog Converter
____________________________________________________________________________________
14
Specifications
Configuration ................................................ Balanced Differential, Stereo
Digital / Analog Power Supply Transformers ..... 25VA / 10VA
Power Supply Capacitance ............................. 26,400µF
Digital Filter / Digital-to-Analog Converters ....... ESS ES9016 Sabre
32 32-bit Hyperstream™
Frequency Response (full range) ..................... 2Hz - 100kHz +0/-3dB
THD @1kHz, 0dBFS (A-weighted) ..................... < 0.001%
Intermodulation Distortion ............................. < 0.001%
Dynamic Range ............................................. > 120dB
Signal-to-noise Ratio ..................................... > 120dB @ full output
Slew Rate ..................................................... 50V/µs
Channel Separation ....................................... > 116dB
Low Level Linearity ........................................ < ±0.25dB at -90dBFS
Intrinsic Jitter ............................................... 1 picosecond RMS
Analog Outputs – Balanced ............................ 1 pair XLR – Fixed Level
Analog Outputs – Single Ended ....................... 1 pair RCA – Fixed Level
Max. Analog Output @ 0dBFS - XLR / RCA ...... 2.0 Volts – Fixed Level
Optional Analog Outputs – Balanced ............... 1 pair XLR – Variable Level
Optional Analog Outputs – Single Ended .......... 1 pair RCA – Variable Level
Max. Analog Output @ 0dBFS - XLR / RCA ...... 4.0 Volts – Variable Level
Analog Output Impedance - XLR / RCA ......... 100 Ω
Bit-depth range / Sampling Frequency .............. 16 to 24 bits / 44.1kHz to 192kHz
Digital Inputs (8)............................................ 2 x AES/EBU , 3 x S/PDIF, 2 x TosLink, 1 x USB
Digital Outputs (1) ........................................ S/PDIF
Digital Monitor Loop ....................................... S/PDIF - 1 input / 1 output
Remote Control ............................................. Full-Function CRM-2
Power Consumption @ idle ............................. 10 watts
AC Power Requirements ................................. 120V / 60Hz or 240V / 50Hz
Shipping Weight ............................................ 16 lbs / 7.5 Kgs
Dimensions (W x H x D, inches) ...................... 16.9 x 3.4 x 13.1
Balanced Pin Assignment:
Pin
1........................... Ground
Pin 2........................... Positive
Pin 3 .......................... Negative
Optional MiND Music Streamer:
Signal Input – Wired ....................................... 100Base-T RJ45 Ethernet interface
Signal Input – Wireless ................................... IEEE 802.11 b/g/n Wi-Fi interface
NOTE: If you require the RS-232 codes for your Nēo 380D, please visit the "Contact Us" page
and complete the "Information request" form on our website at www.simaudio.com.
Fuse Replacement: For the 120V version use a 0.2A slow blow (5 x 20mm size).
For the 230V version use a 0.1A slow blow (5 x 20mm size).
