600i Dual-Mono Integrated Amplifier
____________________________________________________________________________________
12
Assigning a custom label to an input:
1. Using the example from the previous page for
configuring an input, repeat steps 1 through 5.
2. When “CUSTOM” appears in the display press
the “OK” button. The display will show
“……………………………” .
3. Rotate the volume control clockwise to scroll
through the 26 letters of the English alphabet,
first in uppercase and then lowercase, followed
by the numbers 0 through 9, and finally several
miscellaneous symbols including the space
character. When you see the letter, number or
symbol you wish to use, press “OK” to select it
and then repeat this step for the next character.
4. You must assign all 8 characters when creating
a custom input label; If your label requires only
5 characters, you will need to input a blank
space for the remaining 3 characters. Note: If
you decide to create a custom input label for
MiND, it must be spelled exactly as it appears
here – the software is case sensitive.
5. Once you’ve filled the last position, press”OK”
and “SAVED” will briefly appear in the display
followed by “INPUTS”.
6. Press the “SETUP” button to exit from the Setup
menu.
A pair of single-ended RCA connectors labeled “LINE
OUT” can be found on the MOON 600i’s rear
panel. The output level can be configured as either
fixed level (for use with a recording device) or
variable level (for use with a sub-woofer or when
using the MOON 600i only as a preamplifier). This is
done as follows:
1. You may either continue where we left off in the
previous example by pressing “Setup” twice to
return to the main menu and the turn the
volume control until “LINE OUT” appears in the
display OR enter into the “Setup” mode from the
beginning by pressing the “Setup” button and
rotating the volume control until “LINE OUT”
appears in the display.
2. Press “OK” and “VARIABLE” will appear in the
display.
3. To change the output to fixed, rotate the
volume control to alternate from “VARIABLE” to
“FIXED”
4. Press “OK” and “SAVED” will appear briefly
in
the display followed by “LINE OUT”.
The MOON 600i is equipped with a 12 Volt trigger
output. When an input is assigned to the 12 Volt
trigger, the device connected to the trigger will
automatically start-up whenever you switch to that
input. The default setting for all five inputs is on.
When you set the IR input to “Y”, all inputs
previously set to “Y” for that trigger will
automatically be set to “N”. Then the trigger will be
controlled exclusively by an external IR signal. The
following example shows how to configure it:
1. You may either continue where we left off in the
previous example by pressing “Setup” twice to
return to the main menu and the turn the
volume control until “TRIGGER” appears in the
display OR enter into the “Setup” mode from the
beginning by pressing the “Setup” button and
rotating the volume control until “TRIGGER”
appears in the display.
2. Press “OK” and “B1 : Y” will appear in the
display.
