Front Panel
Front Panel
This switch powers up the Velocity ® 120.
When lit, this LED indicates that the Velocity ® 120 is powered and
ready for operation.
This control determines the output level for Channel 1.
This control determines the level of definition for Channel 1. Turning
this control fully counter-clockwise bypasses the Definition circuit,
while turning it fully clockwise provides maximum Definition.
This control determines the output level for Channel 2.
This control determines the mid frequency content for Channel 2.
Turning this control fully counter-clockwise bypasses the Definition
circuit, while turning it fully clockwise provides maximum Definition.
1 POWER switch
2 POWER led
3 LEVEL control
4 DEFINITION control
5 LEVEL control
6 DEFINITION control
