11
Local Console Hotkey Function
Scroll Lock + Scroll Lock + Space Bar Calling OSD menu
Right-button mouse + Esc Calling OSD menu
Scroll Lock + Scroll Lock + Switch to previous port
Scroll Lock + Scroll Lock + Switch to next port
Scroll Lock + Scroll Lock + PgUp / PgDn Switch to previous bank or next bank
Scroll Lock + Scroll Lock + Bank no. + Port no. Switch to specific port
Scroll Lock + Scroll Lock + B
Turn the buzzer ON and OFF
* Default the buzzer is ON
Scroll Lock + Scroll Lock + P
Logout the KVM if password security is ON.
Show up the status windows
Advance hotkeys (for Supervisor login only)
Scroll Lock + Scroll Lock + S
Activate auto-scan mode for connected servers
*Press any key to exit the auto-scan mode
Scroll Lock + Scroll Lock + R
Reset all the KVM settings to factory default
*Except User Security settings
Scroll Lock + Scroll Lock + U
Disable and enable password security
*Default security is ON
Scroll Lock + Scroll Lock + L
To enable / disable the screen saving function
and 10 minutes auto-logout
*Default the screen saving is OFF
Remote Console Hotkey Function
Scroll Lock + Scroll Lock + C Toggle switch between remote & local port
Scroll Lock + Scroll Lock + Q
Turn the buzzer ON & OFF
*Default the buzzer is ON
Scroll Lock + Scroll Lock + S
Activate auto-scan mode for remote & local port
*The scan time interval is 5 seconds
Scroll Lock + Scroll Lock + A Auto-adjust the video signal
Note:
■ Example of “Scroll Lock + Scroll Lock + Bank no. + Port no.”
■ Bank No. : 1 to 8
■ Port No. : 01 to 32
■ e.g. Bank 1 Port 4 : Scroll Lock + Scroll Lock + 1 + 0 + 4
■ e.g. Bank 2 Port 16 : Scroll Lock + Scroll Lock + 2 + 1 + 6
■ You must press the hotkey within 2 seconds
■ A beep sound will be heard for successful entering
■ The numeric keypad is not supported, while in OSD screen, the arrow keys, PgUp, PgDn, and
Enter keys are supported
3-5 Hotkeys for KVM & Remote Console
3-4 IP Operations
Please refer to the IP Manual for information on how to set-up and use the IP functions on compatible Raloy
KVM Switches. The IP Manual can be found at www.Raloy.com/files/Raloy-KVM-IP-Manual.pdf
