1 product overview, 1 package content, 2 structure diagram – Raloy RNX119 User Manual
Page 4: 1 package content 1-2 structure diagram
1
The above package content is only for the single console models. Options
such as KVM, HDMI, DVI-D, AV, audio & DC power may cause package
contents to change.
8
1
3
7
6
7
9
8
LCD interchangeable module kit
Micro switch for screen auto power off
Keyboard interchangeable module kit
Mouse interchangeable module kit
4
9
5
1 x RNX119 Rackmount Console
1 x CE-6 6ft Combo KVM cable
1 x Power cord
8 x M6 screw, cage nut & cup washer
2
6
Carry handle to release the 2-pt lock
2-point lock
Installation Slides
LCD membrane
Membrane switch (KVM option)
1
2
3
4
5
1 Product Overview
1-1 Package Content
1-2 Structure Diagram
