RODE Microphones PinMic User Manual
Page 11
- 11 -
Once the pins are exposed, simply match the receptacles on
the PinMic™ to the pins on the backplate and press on.
After the ‘click’, the PinMic™ will be securely fastened.
There is no need to push the microphone down further.
- 11 -
FI T T I N G YO U R PI N M I C
™
Match the backplate pins to the PinMic™ receptacles
BACKPLATE
UNDERNEATH
CLOTHING
PinMic™
ABOVE
CLOTHING
