RODE Microphones NT4 - Manual (Page 7)

- 7 -
• The NT4 is supplied with both a dual XLR cable
(NT4-DXLR), and a stereo mini-jack cable (NT4-MJ).
• The NT4 may be connected directly to two
channels of a mixer using the twin XLR cable
(marked L and R) supplied, with each channel
panned left and right as required. Connection may
also be made direct to a portable recording device
to enable fi eld/location operation using the 9V
battery supply.
• A stand mount clip (RM3) is included with your
NT4, and should be used to connect the NT4 fi rmly
and safely to a stable microphone stand unless
operating by hand which should only be used
when it is not possible to stand mount the NT4.
• We recommend that all connections made to the
mixer or recorder are made with the attenuation
(gain) set to OFF.
• When fi rst switching the mixer ON and phantom
power is applied to the NT4, or when the
microphone battery power is switched ON, several
seconds should be allowed for the microphone to
stabilise.
Connecting the NT4
