DS4600A QUICK GUIDE
6
Reading Diagrams:
DS4600A-210X (Long Range)
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 15°
Tilt angle = 0°
*Code Resolution:
Standard - for 0.50 mm (20 mils) codes
and greater
*Code Reading Condition:
Standard
* Parameter selectable in WinHost.
4
-4
12
-12
-16
(in)
0
4
20
12
(in)
8
16
0
100 200 300 400 500 600 700 800 900 1000 (mm)
400
300
200
100
0
-100
-200
-300
-400
(mm)
24
28
32 36 40
16
8
-8
0.50 mm (20 mils)
0.60 mm (24 mils)
0.80 mm (31 mils)
1.00 mm (40 mils)
DS4600A-200X (Medium Range)
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 15°
Tilt angle = 0°
*Code Resolution:
High - for 0.30 mm (12 mils) codes and
smaller
Standard - for 0.50 mm (20 mils) codes
and greater
*Code Reading Condition:
Standard
* Parameter selectable in WinHost.
4
2
0
-2
10
8
6
-4
-6
(in)
0
2
6
4
12
(in)
8
10
14 16 18
0
50 100 150 200 250 300 350 400 450 500 550 (mm)
250
200
150
100
50
0
-50
-100
-150
-200
-250
(mm)
20 22
0.25 mm
(10 mils)
0.30 mm
(12 mils)
0.50 mm
(20 mils)
-8
-10
