ContRoLs
22
Manual Transport
When pushing or pulling the mower, be sure to
engage the EZT Hydrogear bypass linkages. The EZT
bypass linkages are located on the rear of the frame,
below the rear engine guard.
Raise the deck into the highest cutting position. •
Pull the EZT bypass linkages out and into the •
slots. Release linkages to hold in the bypass
position.
Release park brake.
•
To reengage the EZT’s to drive, reverse the above •
procedure.
8050-018
Set bypass linkages into slots on both sides
Blade Control Lever
To engage the mower blades, slowly lift the lever up
and into the the lock notch.
8058-074
Mower deck blade control lever in the disengaged position
WARNING!
No adjustments or maintenance to be
carried out unless:
the engine stopped •
the ignition key removed •
the parking brake activated •
