14
THE PORTABLE CAPSTAN WINCH
TM
IS NOT INTENDED FOR LIFTING
PURPOSES.
IMPORTANT: D ON’T GO OVER THE ROPE ENTRY PULLEY OF THE
WINCH WITH THE ROPE (FIGURE 2 BELOW) AS IT WILL CREATE FRICTION AND WILL
REDUCE PULLING CAPACITY. GO UNDER THE ROPE ENTRY PULLEY (FIGURE 1
BELOW). IN THIS CASE, THE ROPE ENTRY PULLEY OF THE WINCH WILL NOT BE USED.
IMPORTANT: AFTER PULLING FOR A FEW SECONDS, RELEASE THE
TENSION AND CHECK THE SOLIDITY OF THE INSTALLATION AND TIGHTEN THE SLING
OF THE TREE/POLE MOUNT AGAIN.
3.4 Oil Alert
TM
system
The GXH-50 Honda engine is equipped with an Oil Alert
TM
system that automatically turns off
the ignition when the oil level goes below a safe level. The Oil Alert
TM
system also turns off the
ignition when the winch is operating at an angle greater than 20 degrees (± 4 degrees). Make
sure that your set-up keeps the winch at a relatively horizontal level while winching and idling.
