Bottom Drain Valve Model A296VB2
w w w . p a r r i n s t . c o m
3
A296VB2 Bottom Drain Valve
*Available in other alloys
1/4-20 X .375 SHSB
SD2520SC10
(3) 1932HC2DE
1" NPT
3556HC
RETAINER
HANDLE
3558HC
HANDLE TEE
3562HC
1/4-28 X 1.00 SHCS
COMP RING (2)
3/4-10
SET PIN
SC3118SC06
3551HC *
REF
JAM NUT
PLUNGER
1/4-28 X .62 SHCS
3561HC
(3) 1932HC3DE
3559HC
STANDOFF
SCREW SHAFT
5/16 X .375 SHSS
VALVE BODY
(3) 3560HC
RETAINING CAP
3550HC *
SCREW SHAFT
3555HC
3554HC
SHIM
638VBHA
SEAL 2
3553HC *
3557HC
3552HC
RETAINER
1" NPT
REF
511VB3 *
SEAL 1
