A699VB Valve
P
arr
I
nstrument
C
ompany
211 53rd Street • Moline, Illinois 61265 USA 1-309-762-7716 • 1-800-872-7720 • Fax: 1-309-762-9453
E-mail: [email protected] • http://www.parrinst.com
670M R00 Revision 11/06/13
A699VB Valve
Notes:
1) * Indicates parts required in special material
2) Substitute (1) 4VB4KL grafoil packing for high-temp
3) Optional fittings for outlet 491HC* Nipple 1/4NPTM × 1/4NPTM
or 308VB* male conn 1/4NPTM × 1/4TUBE
WASHER, MONEL
7VBCM
VALVE BODY
700VB*
LANTERN RING
21VB*
PACKING NUT
235VB
234VB2*
PLUG TIP NEEDLE
20VBHB
VALVE SEAT
2X 4VB3
PTFE PACKING
SEE NOTE 2
233VB
BAR HANDLE
