1108V Oxygen Combustion Vessel
P a r r I n s t r u m e n t C o m p a n y 2
Key Item Description
1 103A Screw Cap
2 230A O-ring 2-3/8 ID Buna-N
3 394A12
394A12CL
Vessel Head, Bare
Vessel Head for Chlorine Service
4 A101A
A101ACL
Vessel Cylinder sold only with 103A Screw Cap as Part
No. AA101A
Vessel Cylinder for Chlorine Service sold only with 103A
Screw Cap as Part No. AA101ACL
5 SC1332SC02 Set Screw
6 463A Needle Plug
7 344A2 Valve Needle
8 378A Packing Cup
9 411A Terminal Nut
10 143AC Insulator Delrin
11 238A O-ring 3/16 ID Buna-N
12 388A Spacer
13 SC1932SC10 Socket Head Set Screw
14 278A3 Adapter Bushing
15 404A2 Defl ector Nut
16 406A Lock Nut
17 5A10 Loop Electrode with Sleeve
18 4A10 Straight Electrode with Sleeve
19 401A Sleeve Insulator
20 96AC Electrode Insulator
21 402A Electrode Core
22 406A Lock Nut
23 407A Valve Knob
24 398A Lock Nut
25 400A
A420A
Valve Needle
Valve Needle with Knob (Nos. 23, 24, 25)
26 397A Compression Nut
27 396A Outlet Valve Body
28 7VBCM Washer Monel
29 20VB Valve Seat Kel-F
Item Complete Assemblies
AA101A Vessel Cylinder with 103A Screw Cap
AA101ACL Vessel Cylinder for Chlorine Service with 103A Screw Cap
A416A3V Vessel Head Assembly
A416A3VCL Vessel Head Assembly for Chlorine Service
*1108V Parts Diagram Key and Parts for the 1108V Oxygen Vessel replace the 1108 Parts Diagram Key and
Parts for the 1108 Oxygen Vessel sections found in the 205M on pages 14-15.
1108V Parts Diagram Key*
