6510 Water Handling System Operating Instruction Manual
- 2 -
Operating Instructions
For the 6510 Water Handling System
Purpose
The 6510 Water Handling System acts as a cooling and circulating water source for
maintaining a constant jacket temperature in the 6200 Isoperibol Calorimeter. It also
provides a convenient and consistent means for filling the bucket in a Parr 6200 or 6100
Compensated Jacket Calorimeter. Either one or two 6200 Calorimeters can be served
from a single 6510 System.
Explanation of Symbols
I On position
O Off position
~ Alternating Current (AC)
This CAUTION symbol may be present on
the Product Instrumentation and literature. If
present on the product, the user must
consult the appropriate part of the
accompanying product literature for more
information.
ATTENTION, Electrostatic Discharge (ESD)
hazards. Observe precautions for handling
electrostatic sensitive devices.
Protective Earth (PE) terminal. Provided
for connection of the protective earth (green
or green/yellow) supply system conductor.
Chassis Ground. Identifies a connection to
the chassis or frame of the equipment shall
be bonded to Protective Earth at the source
of supply in accordance with national and
local electrical code requirements.
Earth Ground. Functional earth connection.
NOTE: This connection shall be bonded to
Protective earth at the source of supply in
accordance with national and local electrical
code requirements.
