Parr Instrument 1108 - Manual (Page 17)

1108 Oxygen Combustion Vessel
w w w . p a r r i n s t . c o m 17
Parts for the 1108 Oxygen Combustion Vessel
1
3
10
30
28
9
19
KEY No. PART No. DESCRIPTION
AA101A............BOMB CYLINDER WITH 103A SCREW CAP
AA101ACL.......BOMB CYLINDER FOR CHLORINE SERVICE WITH 103A SCREW CAP
A416A3............BOMB HEAD ASSEMBLY
A416A3CL........BOMB HEAD ASSEMBLY FOR CHLORINE SERVICE
COMPLETE ASSEMBLIES
2
4
5
6
8
7
11
9
29
7
7
27
26
25
24
23
13
12
15
20
21
22
18
15
14
16
17
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
103A
230A
394A12
394A12CL
A101A
A101ACL
395A2
415A
238A
403A
411A
143AC
238A
388A
SC1932SC10
278A3
404A2
406A
5A10
4A10
401A
96AC
402A
406A
407A
398A
400A
A420A
397A
396A
7VBCM
378A
20VB
SCREW CAP
O-RING 2-3/8 ID BUNA-N
BOMB HEAD, BARE
BOMB HEAD FOR
CHLORINE SERVICE
BOMB CYLINDER SOLD ONLY
WITH 103A SCREW CAP AS
PART No. AA101A
BOMB CYLINDER SOLD ONLY
WITH 103A SCREW CAP AS
PART No. AA101ACL
INLET VALVE BODY
O-RING 7/16 ID BUNA-N
O-RING 3/16 ID BUNA-N
CHECK VALVE
TERMINAL NUT
INSULATOR DELRIN
O-RING 3/16 ID BUNA-N
SPACER
SOCKET HEAD SET SCREW
ADAPTER BUSHING
DEFLECTOR NUT
LOCK NUT
LOOP ELECTRODE W/SLEEVE
STRAIGHT ELECTRODE W/SLEEVE
SLEEVE INSULATOR
ELECTRODE INSULATOR
ELECTRODE CORE
LOCK NUT
VALVE KNOB
LOCK NUT
VALVE NEEDLE
VALVE NEEDLE W/KNOB
(Nos. 23, 24, 25)
COMPRESSION NUT
OUTLET VALVE BODY
WASHER MONEL
PACKING NUT
VALVE SEAT KEL-F
APPROVED
BY
BY
SCALE
DWG NO. DATE
DRAWN
DESCRIPTION
REVISIONS FOR
DATE
1108 PARTS IDENTIFICATION
08-09-05
1:1
CWJ
SIZE C
1108
08-09-05 PJC
PROPRIETARY
NEITHER THE DRAWING
NOR INFORMATION
CONTAINED HEREIN
MAY BE COPIED,
REPRODUCED, OR
OTHERWISE USED
WITHOUT WRITTEN
PERMISSION FROM
PARR INSTRUMENT
COMPANY.
DRAWN IN 3rd ANGLE PROJECTION DO NOT SCALE DRAWING
MOLINE, ILLINOIS 61265
211 53rd STREET
PARR INSTRUMENT CO.
RWOC; 02-08-08 MAW
SHEET 2
480M
REF: 4558AK
