This exciting Ultra Micro Series edition of ParkZone’s wildly popular T-28 is a must-have for
any intermediate to experienced pilot. Like the original, it has plenty of performance for
sport aerobatics but remains a joy to fl y at slower speeds if you want to throttle back and
shoot touch and gos. And, like the original, it boasts remarkably scale lines and a great
looking U.S. Navy trim scheme. Best of all, this one is small enough to fl y in your backyard.
To register your product online, go to http://www.parkzone.com
Safety Precautions and Warnings ................. 3
Introduction ......................................................... 4
First Flight Preparation ..................................... 4
Maintenance Tips ............................................... 4
Battery Warnings ................................................ 5
Low Voltage Cutoff (LVC) ................................. 5
Charging the Battery .......................................... 6
Transmitter and Receiver Binding ................. 7
Installing Transmitter Batteries ....................... 7
Transmitter Controls .......................................... 8
Digital Trims .......................................................... 8
Dual Rate Function ............................................. 8
Control Direction Test ........................................ 8
Reverse Controls .................................................. 9 Control Centering..............................................10
Installing Landing Gear ...................................10
Receiver Control Unit .......................................11
Arming ..................................................................11
Motor Control Test ............................................11
Adjusting Center of Gravity ...........................11
Propeller and Propeller Shaft Maint. ..........12
Flying Tips ............................................................13
Repairs ...................................................................13
Re-binding Transmitter ...................................13
Troubleshooting Guide ...................................14
Replacement Parts and Optional Parts .....15
Warranty and Service .......................................15
Contact Information .........................................16
First Flight Preparation
Remove and inspect contents •
Begin charging the fl ight battery •
Install landing gear •
Install batteries into battery charger •
Install batteries into the included •
transmitter (RTF ONLY)
Install fully charged battery
•
Bind the receiver to a transmitter •
(BNF ONLY)
Perform the Control Direction Test with
•
the transmitter
Adjust fl ight controls and transmitter
•
Adjust battery for center of gravity (CG) •
Perform a radio system Range Check •
Find a safe and open area •
Plan fl ight for fl ying fi eld conditions •
Maintenance After Flying
Disconnect fl ight battery from ESC •
(Required for Safety)
Turn off transmitter
•
Remove fl ight battery from aircraft •
Recharge fl ight battery •
Repair or replace all damaged parts •
Store fl ight battery apart from aircraft •
and monitor the battery charge
Make note of fl ight conditions and fl ight
•
plan results, planning for future fl ights
Table of Contents
T-28 Specifi cations
Wingspan
Length
Weight
16.8 in (426mm)
13.5 in (343mm)
1.30 oz (38 g)
T-28 Features
Bind-N-Fly
Version
Ready to Fly
Version
Onboard Electronics
Spektrum AR6400
Receiver/Servos/ESC
Installed Installed
Battery
120mAh 3.7V 14C
Li-Po
Included Included
Charger
1S 3.7V Li-Po Battery
Charger
Included Included
Transmitter
DSM2 aircraft
transmitter
Sold
Separately
Included
