Thank you for purchasing the ParkZone® Ultra Micro Series Pole Cat. You’re just a battery charge
away from one of the most exciting Ultra Micro fl ying experiences available. This Pole Cat has
been specially designed to look like a full-scale Formula-1 air racer yet remain as forgiving as any
sport plane. Whether you’re banking and yanking at high speed around the pylons, or simply
shooting touch and go landings, the Pole Cat is a joy to fl y at any speed.
Before you take that fi rst fl ight though, please take some time to read through this manual. In
addition to instructions for binding it to your DSM2® or DSMX® transmitter, you’ll fi nd control
setup and charging tips, as well as a handy troubleshooting guide. It’s all here so you can get the
most from your Pole Cat– fi rst fl ight and every fl ight.
To register your product online, go to www.parkzone.com
Table of Contents
EN
Specifi cations .............................................................3
Charging the Battery ...............................................4
Charging Warnings ..................................................5
Low Voltage Cutoff (LVC) .......................................5
Transmitter and Receiver Binding ......................6
Installing the Flight Battery
and Arming the ESC ...............................................6
Prefl ight Checklist ....................................................7
Control Centering ....................................................7
Settings for Control Horns ....................................7
Control Rates ..............................................................8
Model Decals .............................................................8
Adjusting Center of Gravity (CG) .........................8
Control Direction Test .............................................9 Propeller and Propeller Shaft Maintenance....10
Flying Tips and Repairs ........................................ 11
Post Flight Checklist ............................................. 11
Additional Safety Precautions
and Warnings .......................................................... 12
Removing and Installing Landing Gear ......... 12
Troubleshooting Guide ....................................... 13
Warranty and Repair Policy ................................ 14
Warranty and Service Information .................. 15
Compliance Information for
the European Union ............................................. 15
Parts Contact Information .................................. 58
Replacement Parts ................................................ 58
Optional Parts and Accessories ........................ 59
Specifi cations
Installed
Spektrum TM AR6410L Receiver/
Servos/Esc
Included Battery: 150mAh 3.7 25C Li-Po
Included
Charger: 1S 3.7V Li-Po Battery
Charger
Needed to
Complete
DSM2/DSMX 4-Channel Transmitter
15.4 in (391 mm)
16.1 in (409 mm)
1.25 oz (35.3 g)
