EN

AS3X Control Direction Test

Perform the Control Direction Test to ensure the aircraft responds cor-
rectly to your transmitter. Once you are sure the aircraft responds cor-
rectly, move the aircraft as shown to ensure the AS3X system moves
the control surfaces in their proper direction. If the control surfaces
do not respond as shown, do not fl y the aircraft. Refer to the receiver
manual for more information.

The AS3X system will not activate until the throttle stick or trim is in-
creased for the fi rst time after the fl ight battery is connected and the
ESC switch is in the ON position. Once the AS3X is active, the control
surfaces may move rapidly on the aircraft. This is normal. AS3X will
remain active until the battery is disconnected or the ESC switch is in
the OFF position.

Aircraft

movement

AS3X Reaction

Elev

ator

Aileron

Rudder

10
