21 901272
OWNER’S MANUAL
PARTS LIST
LOG SET MODELS VSLR18,
VSLR24, VDLCR18, VDLCR24,
AND VDLCR30
This list contains replaceable parts used in your log set. When ordering parts, follow the
instructions listed under Replacement Parts on page 22 of this manual.
KEY PART NUMBER FOR
NO. VSLR18 VSLR24 VDLCR18 VDLCR24 VDLCR30 DESCRIPTION QTY.
1 — — 901565-02 901566-02 901567-02 Bottom Rear 1
2 — — 901603-01 901604-01 901604-04 Bottom Front 1
3 — — 901593-01 901594-01 901595-01 Bottom Front 1
4 — — — — 901580-02 VR-11\VC Top Log 1
5 — — 901588-01 901588-01 901588-01 VS-12 Top Log 1
6 — — — 901592-01 901592-01 VCR-12 Top Log 1
7 — — 901591-02 901591-02 901591-02 VCR-11\VC Top Log 1
8 — — 901551-03 901551-03 901551-03 CHR-13\VC Top Log 1
9 — — 901587-01 901587-01 901587-01 VCR-9 Top Log 1
10 901625-03 901626-03 — — — Bottom Rear 1
11 901583-01 901584-01 — — — Bottom Front 1
12 901541-02 901541-02 — — — CPR-13\VR Top Log 1
13 901580-01 901580-01 — — — VR-11\VR Top Log 1
14 901579-01 901579-01 — — — VR-10Y Top Log 1
15 — 901578-01 — — — VR-10 Top Log 1
