19 901272
OWNER’S MANUAL
PARTS LIST This list contains replaceable parts used in your log set. When ordering parts, follow the
instructions listed under Replacement Parts on page 22 of this manual.
MODELS VVSA18R,
VVSA24R, VVDA18R,
VVDA24R, AND VVDA30R
KEY PART NUMBER FOR
NO. VVSA18R VVSA24R VVDA18R VVDA24R VVDA30R DESCRIPTION QTY.
1 901063-01 901063-01 901063-01 901063-01 901063-01 Brass 3/8 FLR x 1/2 FPT Elbow 1
2 901056-01 901056-01 901056-01 901056-01 901056-01 Brass 3/8 FLR x 3/8 MPT Elbow 1
3 901066-01 901066-01 901066-01 901066-01 901066-01 Brass Air Mixer - Natural Gas 1
4 901064-03 901064-04 901064-03 901064-04 901064-09 Natural Gas Injector 1
5 901208-01 901208-02 901209-01 901209-02 901209-03 Burner Manifold 1
6 901136-01 901136-02 901137-01 901137-02 901137-03 Burner Pan 1
7 901242-01 901242-01 901242-01 901242-01 901242-01 Damper Clamp - Std. Assembly 1
8 901232-01 901232-01 901232-01 901232-01 901232-01 Gas Line - 12" Aluminum 1
9 901430-01 901430-01 901431-01 901431-01 901431-01 Grate Steps 2
10 901243-01 901243-02 901246-01 901246-02 901246-03 Log Grate 1
11 — — 901681-01 901681-01 901681-01 Burner Strap 1
12 — — 901063-01 901063-01 901063-01 Nut #8/32 1
13 — — 901076-01 901076-01 901076-01 Screw #8/32 x 3/8 1
14 106824-01 106824-01 106824-01 106824-01 106824-01 Piezo Cover 1
15 901066-02 901066-02 901066-02 901066-02 901066-02 Propane/LP Brass Air Mixer 1
16 901065-02 901065-03 901065-02 901065-03 901065-04 Propane/LP Brass Orifice 1
17 901075-01 901075-01 901075-01 901075-01 901075-01 Screw 1/4" #8 “B” pt 1
18 105575-01 105575-01 105575-01 105575-01 105575-01 Jumper Wire 1
19 M12461-26 M12461-26 M12461-26 M12461-26 M12461-26 Machine Screw #10-32 x 3.8" 1
20 097159-04 097159-04 097159-04 097159-04 097159-04 Piezo Igniter 1
21 901071-01 901071-01 901071-01 901071-01 901071-01 Valve, mV 1
22 901073-01 901073-01 901073-01 901073-01 901073-01 Pilot Burner (with natural gas orifice) 1
23 901072-01 901072-01 901072-01 901072-01 901072-01 Piezo Ignitor Electrode 1
24 106823-01 106823-01 106823-01 106823-01 106823-01 Steel Shroud 1
25 901070-01 901070-01 901070-01 901070-01 901070-01 Propane/LP Pilot Burner Orifice 1
PARTS AVAILABLE — NOT SHOWN
901156-01 901156-01 901156-01 901156-01 901156-01 .125# Bag Embers 1
901155-01 901155-01 901155-01 901155-01 901155-01 1.5# Bag Ash Bed Material
(Vermiculite) 1
901838-01 901838-01 901838-01 901838-01 901838-01 Remote Receiver Cover (Log) 1
