35
KeY
NO.
PART NO.
DeSCRIPTION
QTY.
1
**
Outer Casing Top
1
2
**
Baffle
1
3
**
Outer Casing
1
4
104281-02BR Firebox Hood
1
5
**
Firebox Top
1
6
**
Firebox Wrapper
1
7
110339-01CK Outer Base
1
8
102635-02
Front Left and Right Sides
2
9
103209-05
Extruded Louver
2
10
098304-02
Screw, PPH AB 6-20 x .38
8
11
M10908-2
Screw, SLTD HWH TPG 6-32 x .38
4
12
104313-01
Right Pin Hinge
1
13
104313-02
Left Pin Hinge
1
14
103295-05BR Screen Frame
1
15
111038-02
Remote/Blower Bracket
1
16
M11084-26
Screw, HWH AB 10-16 x .38
35
17
111633-01
Box Cover
1
18
111200-01
Support Bracket
1
19
099230-02
Screw, HWH SHLDR AB 10 x .63
14
** Not a field replacement part
paRTs lisT
FIReBOx MODeLS VDC
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 42 of this manual.
