OWNER’S MANUAL
PARTS LIST
This list contains replaceable parts used in
your fireplace. When ordering parts, follow
the instructions listed under Replacement
Parts on page 16 of this manual.
CGCF26NR
KEY
NO.
PART NO. DESCRIPTION QTY.
1 102633-02CK Outer Casing Top 1
2 102624-02 Outer Casing 1
3 099230-02 Shoulder Screw 16
4 098304-01 Screw, #10 x 3/8" 19
5 103447-02 Burner 1
6 104230-02 Louvered Door, Service Assembly 1
7 102635-02CK Left and Right Side Front 2
8 103692-01CK Top Louver 1
9 102730-01CJ Firebox Hood 1
10 102638-01 Firebox Top 1
11 103779-01 ODS/Pilot Assembly 1
12 102460-01CJ Firebox Wrapper 1
13 104322-01 Burner Tube 1
14 103823-02 Remote Set (Includes Transmitter) 1
15 104335-01CK Outer Shell Base 1
16 102649-02CJ Branch Support 1
17 097159-04 Piezo 1
18 098271-07 Ignitor Cable 1
19 098251-10 Injector 1
20 098250-01 Injector Holder 1
21 098249-01 Nut, M5 6
22 103781-01 Gas Valve 1
23 102639-01 Baffle 1
24 101628-01 Flexible Connector 1
25 104305-01 Control Shield 1
26 103295-02CJ Screen Assembly 1
27-1 104058-01 Branch 1
27-2 104077-01 Main Log 1
28 101386-02 Hinge 2
29 099194-11 Rivets 8
30 102645-02 Burner Support, Right 1
31 102645-03 Burner Support, Left 1
32 097809-02 Connector, Male 1
33 101629-01 Bushing 1
34 101629-02 Bushing 1
35 M12461-26 Gas Valve Screws 2
36 098264-02 Connector, Male 1
37 103284-03 Wire Harness 1
38 099387-14 Pilot Tube to Regulator 1
39 099918-02 Regulator Pilot 1
40 099387-15 Pilot Tube, Regulator to Control Valve 1
41 M11084-26 Hex Head Screws #10 x .38 30
42 097403-02 Pan Head Screws 1 3 / 4 " 2
43 102458-01CK Middle Rail 1
PARTS AVAILABLE — NOT SHOWN
103877-01 Lighting Instructions Plate 1
100563-01 Warning Plate 1
103470-01 Hardware Package 1
104319-01 Information Video 1
