Mighty Mule FM145 - Manual (Page 3)

2 3
1 2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PRS
8
TUV
9
WXY
0
A Lock w/ 20' of 16 Gauge Low Voltage Wire
B Lock Receiver
C Keypad
D Clevis Pin
E Locking Cap
F Push Button Entry Control and mounting screws
G Manual Release Keys
H (6) 8" Ty-wraps
I (4) AA Batteries
A
F I
G
H
B
D
E
C
Parts Identification
PLEASE NOTE ... due to the variety of possible mounting applications, no mounting hardware for the lock is
provided. All necessary mounting hardware can be obtained at a local hardware store; all other hardware is
provided. If you need assistance please call GTO® Technical Service at 800-543-1236.
• Features and Warranty ----------------------------------------------------------------------------------- page 1
• Before You Start -------------------------------------------------------------------------------------------- page 2
• Parts Identification ---------------------------------------------------------------------------------------- page 3
• Determine Mounting Location for Lock and Entry Control ---------------------------------- page 4
• Mounting the Lock----------------------------------------------------------------------------------------- page 5
• Mounting the Keypad------------------------------------------------------------------------------------- page 7
• Wiring Connections --------------------------------------------------------------------------------------- page 7
• Keypad Description --------------------------------------------------------------------------------------- page 7
• Typical Installation with Optional Solar Panel or Transformer ------------------------------ page 8
• Programming the Keypad ------------------------------------------------------------------------------ page 9
Table of Contents
