In stick Mod 3 and 4, it helps to tune the helicopter's
sideward flight.
In stick Mod 1 and 2,it helps to tune the helicopter's
left and right direction turning speed.
In stick Mod 3 and 4, it helps to tune the helicopter's
left and right direction turning speed.
In stick Mod 1 and 2,it helps to tune the helicopter's
sideward flight.
In stick Mod 1 and 3, this button is null.
In stick Mod 2 and 4, it helps to tune the helicoper's forward
and backward flight.
It controls the power source of the transmitter.Slide
the power switch to the “ON” position, the transmitter
is powered on; slide the power switch to the “OFF”
position, the transmitter is powered off.
No. Function switch Function description
Trimmer B
5 Trimmer C
6 Trimmer D
7
8
Power switch
Antenna
9
Power
indicator
Transmits wireless signal.
The indicator light keeps blinking slowly: the transmitter
is not activated.
The indicator light keeps flashing rapidly: the transmitter
is sending out connectional signal to the helicopter.
The indicator light keeps on without blinking: the
transmitter is ready for controlling the flight.
10
Throttle limit
knob
The throttle of the helicopter can be adjuted by this button,
player can use this button to increase or decrease the
helicopter's upward/downward speed.
11
12
13
Throttle
changing button
Slide down or slide up the 2 buttons at the same time
to select the throttle control stick
There are 3 flight modes of the helicopter: low speed, medium
speed and maximum speed.
aileron/rudder
changing button
Also named Stick Mode changing button.Press this button
to change the control stick mode.
flight mode
changing button
Remote controller’s setting
Select the throttle control stick
There is 1 throttle button on either side of the remote controller.
Slide both of the 2 buttons to "R", the right stick is the throttle control stick.
Slide both of the 2 buttons to "L", the left stick is the throttle control stick.
Tip: both of the 2 buttons should be either on the position of "R" or "L",
otherwise, the remote controller can not be activated.
