Section 6 – Audio Configuration
RadianceXS rev 091211 27
Output 2 should have audio only since the TV cannot accept 1080p60. When you watch TV you would select
720p video output, and turn on the video output on HDMI Output 2. One option is to set MEMA to output
1080p (and disable output 2 video), and MEMB to output 720p on both outputs. Audio can be set as:
If Out1
video on
Else if Out2
video on
Else
Off On Off
Off On Off
Audio Outputs
HDMI1 HDMI2 SPDIF
Condition uses Audio EDID
Off Off On
User EDID PCM 2Ch 48Khz Y
Out2 EDID
Out2 EDID
Norm
Norm
Norm
Audio User EDID
When selecting specific audio modes, the up and down arrow keys select an entry and the right arrow key is
used to turn that mode on or off.
Input Memory Specific Audio EDID
If an input, or input memory, requires a specific EDID, it can be configured in the audio setup menu. Each
input memory can be configured to use the global audio EDID, or a specific list of audio modes to report
back to the source. The command is:
MENU → Input → Audio Setup → Audio EDID
Audio Source Selection Defaults
To change the audio source for a particular input, first select that video input, and then select the desired
audio source. Any number of video inputs can be linked to the same audio source. The command is:
MENU → Input → Audio Setup → Source → (select audio input) → OK
The video inputs are linked to the following audio sources by default.
Input
Number
Video Input
Type
Audio
source
1 HDMI HDMI1
2 HDMI HDMI2
3 HDMI HDMI3
4 HDMI HDMI4
5 Svideo Tos2
6 Svideo Coax2
7 Component Tos1
8 Component Coax1
9 Composite Stereo1
10 Composite Sterio2
