Billet Trim Tab Installation
2 of 11
715 Center Street Grayslake IL 60030 P: 847.752.2700 E: [email protected] www.livorsi.com
REV B MAY 2015
TTK EL Models
Mounting tab location cont.
Transition of the hull to tabs:
Recommended Transtion:
Allows tab to be removed fully from the water flow underneath the boat while under way.
Some applications may require the tab to be mounted even higher to be out of the water flow.
