Page 11.
Many other items are available from LPE for your Cadillac CTS-V including low temperature
thermostats, camshafts, ported throttle bodies and much more. Contact LPE, visit our web site, or
contact your LPE distributor for information about our other products.
For additional product installation information and technical support, contact LPE or your LPE
products distributor. You can also find technical support and usage discussions regarding this product
and many other LPE products in our Internet forums:
http://www.lingenfelter.com/LPEforumfiles
Figure 1: Belt routing diagram
CRANK
LOWER
IDLER
UPPER
IDLER
SUPERCHARGER
TENSIONER
