SPECIFICATIONS
*ALL SPECIFICATIONS ARE BASED ON THE LATEST PRODUCT INFORMATION AT THE TIME OF PRINTING.
WE RESERVE THE RIGHT TO MAKE CHANGES AT ANY TIME WITHOUT NOTICE.
MODELS LP15
ENGINE TYPE WATER COOLED 4-CYCLE
DISPLACEMENT 19.71 cu. in (323 cc)
BORE X STROKE 2.32 in X 2.32 in (59 mm X 59 mm)
GEAR RATIO 2.08 (27/13)
GEAR SHIFT F – N – R
TRANSOM HEIGHT
SHORT SHAFT 15 in (381 mm)
MAX OPERATING R.P.M.
1000 100 R.P.M. IDLE SPEED
4500-5500 R.P.M.
IGNITION TYPE ELECTRONIC CDI
IGNITION SWITCH TETHER / KEY (ELECTRIC START MODELS)
VALVE CLEARANCE IN and EX (COLD)
SPARK PLUG GAP 0.020-0.024 in (0.5-0.6 mm)
LUBRICATION OIL TYPE
CRANKCASE OIL CAPACITY 1.06 US qt. (1.0L)
FUEL
STARTER PULL CHORD AUTO REWIND AND/OR TURN KEY SWITCH
PROPANE
4 STROKE 10W-30
SPARK PLUG TORQUE SPEC 13.3 ft.•lb. (18.0 N•m)
GEAR OIL TYPE / CAPACITY
SPARK PLUG TYPE NGK DPR6EA-9
POWER 15 hp (11.2 kW) @5000 R.P.M.
WEIGHT
INTAKE: 0.0032-0.0047 in (0.08-0.12mm)
EXHAUST: 0.0032-0.0047 in (0.08-0.12mm)
HYPOID GEAR OIL SAE#90 0.26 US qt. (0.250L)
LONG SHAFT 20 in (508 mm)
(S) SHORT SHAFT
(L) LONG SHAFT
(ES) ELECTRIC START, TILLER, SHORT SHAFT
(EL) ELECTRIC START, TILLER, LONG SHAFT
(ES IB) ELECTRIC START, TILLER, SHORT SHAFT, INTERNAL BATTERY
(EL IB) ELECTRIC START, TILLER, LONG SHAFT, INTERNAL BATTERY
(ERS) ELECTRIC START,REMOTE STEERING, SHORT SHAFT
(ERL) ELECTRIC START, REMOTE STEERING, LONG SHAFT
(S) 110 lbs (49.9 kg), (L) 114 lbs (51.7 kg)
(ES) 120 lbs (54.4 kg), (EL) 124 lbs (56.3 kg)
(ESIB) 122 lbs (55.3 kg), (ELIB) 126 lbs (57.2 kg)
(ERS) 118 lbs (53.5 kg), (ERL) 122 lbs (55.3 kg)
+-
PROPELLER NUT TORQUE SPEC 12.5 ft•lb (17.0 N•m)
OIL DRAIN PLUG TORQUE SPEC 20.7 ft•lb (28.0 N•m)
INTERNAL BATTERY TYPE LITHIUM IRON PHOSPHATE LiFePO4
