11
11 Re-assembling the Resuscitator
To re-assemble the resuscitator, perform the steps described under Section 9 - Dis-assembling
the Resuscitator, in reverse.
12 Storage
For clinical use, store according to local protocol. For training, keep in the supplied
resuscitator’s storage pouch.
13 Glossary of symbols
0434 This product is in compliance with the essential requirements of Council
Directive 93/42/EEC as amended by Council Directive 2007/47/EC.
LATEX
This product does not contain latex.
14 Technical Information
Product meets ISO 10651-4:2002/EN ISO 10651-4:2009, Lung ventilators- Particular
requirements for operator-powered resuscitators
Operating Temperature:
- 18 °C to 50 °C
Storage Temperature: - 40 °C to 60 °C
Tidal volume: 161 ml* +/- 15 ml (standard deviation) at room temperature
* In sub-zero temperatures, the tidal volume may be approx. 20% less.
Expiratory Resistance:
<2.5 cm H
2
O at 5 LPM
Inspiratory Resistance: <0.5 cm H
2
O at 5 LPM
Dead Space: 4 ml (water volume)
Materials
Hard plastic components: Polysulfone (PSU)
Soft plastic components: Silicone rubber (SI)
Spring: Stainless Steel
External dimensions (with mask): Approx. 220 mm x 70 mm x 120 mm
Mass (with mask size 1): Approx 170 grams
