21
Product Service 1-800-522-7658
C C
H H A A P P T T E E R R
5 5
U U
S S I I N N G G
Y Y
O O U U R R
P P
U U R R I I
C C
A A R R E E
Operating the Sash
The sash of the Vertical Flow Station can be locked in
the full open position. To lock the sash open:
1. Grasp the bottom edge of the sash, and pivot it up
until the sash is fully opened.
2. Locate the sash locking bolt on the inside left side
of the sash, as shown in Figure 5-1.
3. Restrain the sash by aligning the bolt with the hole
in the left side wall of the station, and pressing the
bolt to the left until it engages the hole.
4. To release the sash, support the bottom edge while
pulling the bolt to the right. Allow the sash to pivot
down to its closed position, ensuring that the sash is
set in the closed position.
