SPECIFICATIONS
8
Specifications (Rapid Digestor, 25-Place)
1. Electrical
Operating Voltage:
208-240V AC single phase
Current (Max.):
16 Amp at 230V AC
Fusing:
25 Amp fuses @208 or 240V AC
operation
Frequency:
50 or 60 Hz
2. Physical
Weight:
Digestion Unit:
78 lbs.
Control Unit:
10.8 lbs.
Tubes:
9.2 lbs./set of 25
Flask Rack:
3.6 lbs.
End Plates:
1.4 lbs.
Size
Digestion Unit:
8" H x 19-1/4"W x 19" D
Control Unit:
5-1/8"H x 8" W x 12-1/8"D
Flask Rack:
6-1/2"H x 14-1/4"W x 14-1/4"D
Flask Rack w/ handles
6-1/2"H x 17-3/4"W x 14-1/4"D
End Plate:
6-1/2"H x 14-9/16"W x 1"D
Tubes: Volumetric
11-15/16"L x 1.65 OD
Straight
11-15/16"L x 1.65 OD
Sample Size:
Up to 5 grams
3. Features
Digestion Tubes (Types)
250 ml straight
250 ml constricted with volumetric mark
Capacity
(samples/digestion)
25
Temperature range
Ambient to 450°C
Heat-up time to 410°C
Approximately one hour
Temperature readout
Set point dial with indication lamps
