Chapter 2: Installation
Product Service 1-800-522-7658
6
The Two and Six-Place Kjeldahl Distillation Systems do not include a
surrounding safety enclosure. Labconco advises installing these products in a
fume hood, or if installed on the open laboratory bench, a safety shield should be
placed in front of the burners. High heat and boiling Sodium Hydroxide present a
safety hazard to personnel in close proximately to the Kjeldahl Distillation
Systems. Labconco also recommends spot exhaust ventilation for an open bench
installation to remove excess heat produced by the heaters.
Electrical
The Two-Place Kjeldahl Distillation System comes with an 8-foot, 3 wire cord
and plug and can be connected to a 115 volt 60Hz 11 Amp circuit.
The Six-Place Distillation Kjeldahl System has been wired at the factory per the
product model number ordered by the customer. Labconco model numbers ending
in 01 are 115 volts. Model numbers ending in 02 are 230 volts. Models ending in
03 are 230 volt, three phase. Amperage requirements vary depending on the
number of heaters per the Distillation rack. The voltage and amperage table below
provides the electrical requirements for the Six-Place Distillation Systems. A
qualified electrician will need to connect the facility electrical supply to the main
breaker box of the Digestion System.
1. Remove circuit breaker box cover panel.
2. Main line lead connection terminals are identified and connections
must be made accordingly.
3. Line leads to the apparatus must conform to local electrical codes.
4. Provide an electrical ground to the apparatus per code.
5. Before applying power to apparatus, check the electrical panel and
breakers for loose connections.
6. Reinstall box cover panel.
7. Power the breaker box and reset breakers to check circuits in the
apparatus.
8. All electrical wiring and connections must conform to local codes and
should be performed by qualified electricians. An earth ground must
be provided.
Six-Place Distillation System Electrical Code
Code #
AC Electrical Codes
01
115 volt, single phase, 50/60 Hz, 32 amps
02
230 volt, single phase, 50/60 Hz, 16 amps
03
208/230 volt, three phase, 50/60 Hz, 9 amps
