3
SETUP AND OPERATING PROCEDURES
1. BATTERY LOADING
a. Open battery cover at the back of the monitor.
b. Load four “AA” size batteries. Please pay attention to polarity.
c. Close the battery cover.
When LCD shows battery symbol , replace all batteries with new
ones.
Rechargeable batteries with a voltage of 1.2V are not suitable for this
monitor.
Remove the batteries if the monitor will not be used for a month or more
to avoid damage or battery leakage
2. ON/OFF SWITCH
Your device has a touch button as equipment. Be careful not to touch the
button by mistake. Keep the ON/OFF switch in “OFF” position when the
device is not in use to avoid unintentional adjustments.
3. CLOCK AND DATE ADJUSTMENT
a. Once you install the battery or turn off the monitor, it will enter Clock Mode, and LCD will display time and date
b. While the monitor is in Clock Mode, press the “START” and “MEM” button simultaneously for two seconds (ON/OFF
switch in ON position), the month flashes at first. Press the button “START” repeatedly, day, hour and minute will flash
in turn. While the number is flashing, press the button “MEM” to increase the number. Keep on pressing the button
“MEM”, the number will increase fast.
c. You can turn off the monitor by pressing “START” button when the minute is flashing, then time and date are
confirmed.
d. The monitor will turn off automatically after 1 minute if no operation with the time and date unchanged.
e. Once you change the batteries, you should readjust the time and date.
4. CONNECTING THE CUFF TO THE MONITOR
Insert the cuff tubing connector into the socket in the left side of the monitor. Make sure that the connector is completely
inserted to avoid air leakage during blood pressure measurements.
External power supply socket
