Application diagram, Dss / satellite receiver with remote control, Stereo system with remote control – Konig Electronic Infrared remote control extender User Manual
Page 5
APPLICATION DIAGRAM
IR Remote
Control
IR-EGGS2
Transmitter
IR-EGGS2
Receiver
Probe
Stereo
Wire to Extension Speaker
IR-EGGS2
Transmitter
2nd TV
2. DSS / Satellite Receiver with
remote control:
1. Stereo system with remote control:
IR Signal
RF Signal
IR-EGGS2
Receiver
IR Remote
Control
Wall
Wall
DSS or Satellite
Receiver
