INSTRUCTIONS FOR USE
6
Razor SV17
— 909 6309 000(1)2006-01
TECHNICAL DATA
Wiring diagram
(See Fig. L)
CH1: Battery charger
C1:
Battery charger connector
EB1: Electronic board (CF BA430)
EB2:
Electronic board led (CF BALED)
ES1: Brush/pad switch
ES2: Vacuum switch
ES3: Battery charger relay
EV1: Water solenoid valve
F1: Brush fuse (40A)
F2: Vacuum fuse (40A)
F3: Solenoid valve and electronic board fuse (5A)
IS1: Negative insulator
M1: Brush/pad motor
M2: Vacuum system motor
SW1: Brush/pad switch
SW2: Vacuum switch
Colour code
BK: Black
BU: Blue
BN: Brown
GN: Green
GY: Grey
OG: Orange
PK: Pink
RD: Red
VT: Violet
WH: White
YE: Yellow
ELECTRICAL FUSES
The following fuses are located under the cover (1, Fig. I):
–
Brush (40A): (2, Fig. I)
– Vacuum (40A): (3, Fig. I)
– Solenoid valve and electronic board (5A): (4, Fig. I)
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be
equipped with the following accessories/options, according
the machine specific use:
–
Brushes/pads of different materials;
– Electronic battery charger.
For further information concerning the above-mentioned
optional accessories, contact an authorized Retailer.
General Values
Cleaning width 17.0 in (430 mm)
Machine width (without squeegee) 22.4 in (570 mm)
Minimum machine length with adjustable
handlebar
36.6 in (930 mm)
Minimum machine height with adjustable
handlebar 40.2/44.7 in
(1,020/1,135 mm)
Squeegee width 28.3 in (720 mm)
Machine weight (with batteries, battery
charger and brush)
233.70 lbs (106 Kg)
Central (fixed axle) wheel diameter 9.8 in (250 mm)
Brush/pad diameter 17.0 in (430 mm)
Wheel pressure on the ground <0.5 N/mm
2
Brush/pad pressure on the ground (with full
tank)
50,6 lbs (23 Kg)
Battery compartment size (length x width x
height) 13.8 x 13.8 x 10.2 in
(350 x 350 x 260 mm)
Performance Values
Vacuum
41.5 in H 2 O
(1,055 mm H 2 O)
Sound pressure level 67 dB (A)
Vacuum system motor power 330 W
Brush/pad motor power 520 W
Battery voltage 24 V
Standard batteries 12 V, 50 Ah
Clean water tank capacity 8 gal (31 liters)
Recovery water tank capacity 7.9 gal (30 liters)
