the Delta 19 User Manual
head may follow to become loose, so do remember to tighten it before re-screw
the atomizer base on the tube.
• Please do take ten puffs under 4.0 Voltage in first use is case that the new
atomizer head get damage under high voltage mode.
Precautions
1. Only have your Delta 19 repaired by Joyetech. Do not attempt to repair the unit
by yourself as damage or personal injury may occur.
2. Do not leave the Delta 19 in high temperatures or damp conditions, as this may
damage the device. The appropriate operation temperature is within 0� to 45� .
3. Do not attempt to combine the Delta 19 with parts from other brands of
e-cigarettes. If it is damaged in this way, Joyetech will not take responsibility and
your warranty will be void.
Warranty terms
Please consult your Joyetech product warranty card. We are not responsible for any
damage caused by user error. Our warranty is not valid for products purchased
from third party vendors.
Joyetech agrees to provide repair under warranty pursuant to the following
terms and conditions:
1, This warranty provides repair free of charge for defective Joyetech brand
merchandise. Warranty period is 90 days from date of purchase by the end user.
2, This warranty may be void as a result of any of the following conditions:
* Customer does not provide warranty card and original receipt of purchase.
* Merchandise failure or damage is caused due to improper use or unauthorized repair.
* Merchandise failure or damage as a result of excessive force such as dropping.
* Merchandise failure or damage as a result of usage outside of recommended
operating conditions (see precautions in usage manual).
* Merchandise failure or damage caused by improper use of water or other liquid
(see usage manual for operating instructions).
* Merchandise failure or damage due to usage with non-Joyetech components
(charger, battery, and power cable).
3, This warranty does not cover personal items or consumable goods and
attachments, including but not limited to: mouthpiece, cartridge, atomizer head,
lanyard, and leather sheath.
4, This warranty does not cover any non-Joyetech brand products. This warranty is
only valid for eligible Joyetech brand products during the warranty period of 90 days
after date of purchase as indicated on proof of purchase.
Joyetech reserves the right of final decision in all warranty cases.
Joyetech may interpret and revise the content of this warranty terms.
Joyetech (Shenzhen) Electronics Co., Ltd.
Email:[email protected]
Notice for Use
Thank you for choosing Joyetech! To ensure safe and proper usage, please read
this manual carefully. If you require any additional information or have any
questions regarding this product or its use, please consult your local Joyetech
retailer, or visit our website at www.joyetech.com.
Product Introduction
The 3.5 large e-juice volume and two adjustments of air inflow highlight the Delta
19. Replaceable mouthpiece and atomizer head are available on Delta 19 due to
C3 Dual atomizer head. Not only that, but the Delta 19 features three glass e-juice
windows, making the liquid volume more open-and-shut. Regarding to its material,
the all stainless steel construction creates an environmental puff.
Specification
Delta 19:
Size: 23mm*87.8mm(including mouthpiece and base)
Capacity: 3.5ml
Color: Black, Silver
C3 Dual Atomizer Head:
Size:8.5*20.6mm
Resistance: 1.6ohm
Working voltage range: 3.5-5.5V
Working wattage range: 6.8-16.8W
How to Assemble
1. Screw the C3 atomizer head onto the Delta 19 atomizer base along the clockwise.
2. Screw the base onto the Delta 19 atomizer tube along the counterclockwise.
3. Plug on the replaceable mouthpiece.
How to Use
360°Adjustment of air inflow: Rotating the ring on the atomizer
base clockwise or counterclockwise to adjust the inlet valve.
There are two slots on the atomizer base. The less the slot be
obscured by, the bigger the air inflow is.
Liquid filling
Unscrew the atomizer tube from the Delta 19 base. Simply refill e-Liquid into the
hole from the bottom along the inwall of Delta 19 atomizer tube.
Several key points:
• Please do not refill the e-liquid into the small hole in the center of the atomizer tube.
• When you unscrew the Delta 19 base from the atomizer tube, the atomizer
Atomizer Tube Mouthpiece Atomizer Head Atomizer base
