Hope Tech Conventional Headset - Manual (Page 2)

CUP STYLE HEADSET INSTRUCTIONS
Remove all sharp edges.
With 8mm allen key, adjust Head Doctor (items 12 to 16)
until a slide fit inside steerer and insert it 10mm into
steerer.
Tighten until solid in steerer.
4/ FINAL ASSEMBLY :
Liberally apply good quality waterproof grease to all
bearings (4) and sealing surfaces. When fitting ensure
that the top seal (6) is fitted correctly.
Insert forks into frame.
Over the steerer, fit upper taper ring (5), shims (8) if
necessary, sealing cover (6) and top cover (7) with o’ring
(9). You may have to stack several 0.4mm shims (8) to
reduce the drag of the top seal (6).
Fit stem and top cap (10). Tighten bolt (11) in top cap
until forks rotate smoothly without play or restriction.
Clamp stem to manufacturer recommended torque.
The headset may need adjustment after the first few
rides, this is normal due to the settling of the compo-
nents.
1/ FITTING CUPS :
Firstly, ensure both ends of head tube are parallel and of
correct size. If necessary ream the bore and face each end
of the head tube.
Chamfer the inside edges of the head tube at both ends.
Press in both cups (2 and 3) using a headset press fitted
with Hope adaptors. Use the laser etched Hope logo to
ensure the cups are fitted in the correct end of the head
tube.
2/ FITTING CROWN RACE :
Slide the fork crown race (1) onto the steerer tube with
the flat side to the bottom. Then slide the bottom bearing
(4) on top of the fork crown race (1).
3/ CUTTING STEERER :
Fit forks into frame. Slide the complete top assembly and
stem over steerer. Ensure all parts are pushed together
firmly.
Scribe a line flush with the top of the stem.
Remove stem and cut steerer in a straight line 3mm
below the line.
CUP STYLE HEADSET INSTRUCTIONS
Remove all sharp edges.
With 8mm allen key, adjust Head Doctor (items 12 to 16)
until a slide fit inside steerer and insert it 10mm into
steerer.
Tighten until solid in steerer.
4/ FINAL ASSEMBLY :
Liberally apply good quality waterproof grease to all
bearings (4) and sealing surfaces. When fitting ensure
that the top seal (6) is fitted correctly.
Insert forks into frame.
Over the steerer, fit upper taper ring (5), shims (8) if
necessary, sealing cover (6) and top cover (7) with o’ring
(9). You may have to stack several 0.4mm shims (8) to
reduce the drag of the top seal (6).
Fit stem and top cap (10). Tighten bolt (11) in top cap
until forks rotate smoothly without play or restriction.
Clamp stem to manufacturer recommended torque.
The headset may need adjustment after the first few
rides, this is normal due to the settling of the compo-
nents.
1/ FITTING CUPS :
Firstly, ensure both ends of head tube are parallel and of
correct size. If necessary ream the bore and face each end
of the head tube.
Chamfer the inside edges of the head tube at both ends.
Press in both cups (2 and 3) using a headset press fitted
with Hope adaptors. Use the laser etched Hope logo to
ensure the cups are fitted in the correct end of the head
tube.
2/ FITTING CROWN RACE :
Slide the fork crown race (1) onto the steerer tube with
the flat side to the bottom. Then slide the bottom bearing
(4) on top of the fork crown race (1).
3/ CUTTING STEERER :
Fit forks into frame. Slide the complete top assembly and
stem over steerer. Ensure all parts are pushed together
firmly.
Scribe a line flush with the top of the stem.
Remove stem and cut steerer in a straight line 3mm
below the line.
