Charger layout – HITEC X4-Eighty: DC/DC, Four Port Multi-Charger User Manual
Page 5
03
CHARGER LAYOUT
LCD Screen
Menu Control Buttons
Battery
Battery Sockets
Universal Balancing
Port Pitch=2.54mm
Universal Balancing
Port Pitch=2.54mm
Temp Sensor PC Link
Available for
1 & 3 only
output
Temp Sensor PC Link
Available for
2 & 4 only
output
Ventilation Fan
with Temperature
Sensor Control
Sockets
Battery
Sockets
Ventilation Fan
with Temperature
Sensor Control
