02
INTRODUCTION
Power Source
Charge Power
Discharger Power
Cell Count
Current Drain for Balancing Lithium
Charge Termination
NiCd/NiMH
Lead-Acid and Lithium
Dimensions
Net Weight
12V DC Car Battery or
11-18V DC Power Supply
80 Watts, current is regulated accordingly
e.g. 11.1 V battery, charge current approx. 6.0 A
e.g. 22.2 V battery, charge current approx. 3.6 A
10 Watts, current is regulated accordingly
1-15 NiCd/NiMH cells
1-6 LiPo/LiIon/LiFe cells
1-10 Lead-Acid cells (2V - 20V)
300mA
Automatic, negative delta-peak method
Automatic, voltage-dependent, CC-CV process
8.9 x 6.3 x 2.4 in.
2.5 lbs.
Operating Voltage Range DC 11-18 Volts
The Hitec X4-80 allows you to charge up to four different batteries simultaneously. The
charger will automatically charge all 4 batteries at a time to their maximum capacity. Addi-
tionally the batteries being charged do not need to have the same configuration or the
same chemistry. Therefore you can connect any one of a NiMH/NiCD/LiPo/LiFe battery
into any of the charging ports. This eliminates the time consuming efforts of charging all
your batteries separately.
Specifications
