Specifications - JH 15T17 MMC-MAx-SORx (LED version)
SPECIFICATIONS
Note: All specifi cations are subject to change without prior notice!
Please visit www.hatteland-display.com for the latest electronic version.
2/2
• Operating : Temperature -15 deg. C to +55 deg. C
Humidity up to 95%
• Storage : Temperature -20 deg. C to +60 deg. C
Humidity up to 95%
• IP-Rating : Protection (EN60529): IP66 front - IP66 rear
• W:361.00 [14.21''] x H:289.00 [11.38''] x D:87.00 [3.43''] mm [inch]
• Weight: 7.8 kg
• For mounting unit, use torque 5.1 -> 5.2 Newtonmeter (nM) on screws.
Multi-power Supply:
• 115&230VAC - 50/60Hz + 24VDC
Note: You may connect either AC power or DC power or both. In case both sources
are connected, power will be sourced from the AC input. If AC input is lost, there will
be a uninterrupted switch-over to DC input.
Power Consumption:
• Operating : 60W (max)
: 50W (typ) at max backlight+high CPU (Core2) load
Lifetime Considerations:
Even although the test conditions for bridge units provide for a maximum
operating temperature of 55°C, continuous operation of all electronic
components should, if possible, take place at ambient temperatures of only
25°C. This is a necessary prerequisite for long life and low service costs.
• Capacitive Touch screen (-SORC)
• Up to 4GB of memory
• CPU #1 - Intel® Core™2 Duo L7400 - 1.5GHz, 4MB Cache, 667MHz FSB
• CPU #2 - Intel® Celeron® M ULV 423 - 1.06GHz,1MB Cache, 533MHz FSB
Note: CPU #1 needs additional fan inside MMC unit.
API: Internal SCOM interface, COM3 to control internal display
features. Please review the following document for a complete set of
commands. http://www.hatteland-display.com/pdflink/inb100018-3.php
Power Button : Unit is powered on based by settings in BIOS
(Wake-On-Lan etc.) when power cable is connected.
Reset Button : Not implemented
HDD LED : Not implemented
Power LED : Not implemented
• Installed OS : None or Microsoft® Windows® Embedded
Enterprise (XP Professional Eng w/SP2c, 32bit)
See also Accessories (HT 00300 MSOS) options
• Storage : 40GB, 80GB, 120GB or 300GB SSD (SATA 2.5”)
• Processor : See option table below
• Installed Memory : 2 x 1 GB 667MHz DDR2 Non-ECC CL5 DIMM
• System Chipset : Intel® 82945GME
• Graphics Chipset : Intel® 945GME Integrated
• BIOS : Award BIOS, supports ACPI
• Speaker : None
• Buzzer : Yes, 3500Hz
• Power Manager : ACPI
• Monitoring : Temperature, voltage and fan monitoring
• Resolution Range : From 640 x 480 up to 2048 x 1536 @ 85 Hz*
• RGB OUT Resolution : From 640 x 480 up to 1600 x 1200
* Native 1:1 resolution recommended is 1024 x 768 @ 60 Hz.
* If resolution is set above 1:1, desktop scrolling mode will be used.
• Ethernet GBLan : 2 x RJ-45
• Keyboard : 1 x PS/2
• Mouse : 1 x PS/2
• COM : 2 x DB9M (RS-232/422/485 opto-isolated)
• LPT1 : 1 x DB25F (Bi-directional/ECP/EPP)
• USB 2.0 Type A : 4 x USB
• DVI/RGB OUT : 1 x 29P DVI-I or as RGB with adapter
(DDC on RGB as default)
• Compact Flash : 1 x CF Socket (Type I/II)
• AC Power : Std IEC inlet
• DC Power : 1 x 2p D-SUB (male) - Amphenol FCC17
A P P R O V A L S & C E R T I F I C A T E S
Input/Output Connectors:
Environmental Considerations:
Power Specifications:
Physical Considerations:
This product have been tested / type approved by the following classification societies:
IEC 60945 4th (EN 60945:2002) IACS E10 IP66 ClassNK - Nippon Kaiji Kyokai
GL - Germanischer Lloyd DNV - Det Norske Veritas ABS - American Bureau of Shipping
BV - Bureau Veritas LRS - Lloyd's Register of Shipping EU RO MR - Mutual Recognition
Compass Safe Distance: JH 15T17 MMC-MAx-SORx Standard: 75cm Steering: 45cm
Factory Options:
Processor Options:
User Controls / Interface:
Computer Specifications:
For a full overview of model typenumbers, please review the following link:
www.hatteland-display.com/pdflink/ind100780-2.php
• JH C01MF A-A = USB Cable 1m, Type A to Chassis mount receptacle
• HT 00300 MSOS = OS options -> http://www.hatteland-display.com/os
*Please see user manual/datasheet for more information
Available Accessories:
• Native Resolution : 1024 x 768
• Pixel Pitch (RGB) : 0.297 (H) x 0.297 (V) mm
• Response Time Standard : 8ms (typical), black to white
• Contrast Ratio Standard : 700:1 (typical)
• Light Intensity Standard : 400 cd/m² (typical)
• Viewable Angle Standard : +/- 80 deg. (Up/Down/Left/Right) (typical)
• Active Display Area : 304.1 (H) x 228.1 (V) mm
• Max Colors : 16.7 million
• High Quality TFT with LED Backlight Technology
• Optical Bonding Technology
• 15.0 inch viewable image size, Aspect Ratio 4:3
• TFT active-matrix liquid crystal panel
TFT Technology:
TFT Characteristics:
