SPECIFICATIONS EC 214
1) Liquid Crystal Display (LCD)
2) Conductivity calibration knob
3) 199.9 μS key for range selection
4) 19.99 mS key for range selection
5) 199.9 mS key for range selection
6) 1999 μS key for range selection
7) COND/°C key, to select conductivity reading or temperature
setting for manual compensation
8) Temperature setting knob for manual compensation
9) ON/OFF switch
10) Power adapter socket
11) Probe connector
FUNCTIONAL DESCRIPTION EC 214
Range 0.0 to 199.9 μS/cm / 0 to 1999 μS/cm
0.00 to 19.99 mS/cm / 0.0 to 199.9 mS/cm
Resolution 0.1 μS/cm / 1 μS/cm
0.01 mS/cm / 0.1 mS/cm
Accuracy (@20°C/68°F)
±1% FS (excluding probe error)
Typical EMC Deviation ±1% F.S.
Calibration Manual, single point, through front knob
Temperature Compensation
Manual, 0 to 50°C (32 to 122°F) with β=2%/°C
Probe HI 76300, platinum 4-ring sensor,
with 1 m (3.3') cable (included)
Power Supply 12 Vdc (power adapter included)
Environment 0 to 50°C (32 to 122°F);
RH max 95% non-condensing
Dimensions 240 x 182 x 74 mm (9.4 x 7.1 x 2.9")
Weight 1.0 kg (2.2 lb.)
