HI 322N

HI 324N

Maximum

5 Liters

Stirring

(1.3 gallons) (1.3 gallons)

Capacity

Speed Range
Min.

100 rpm

Max.

800 to 1000 rpm

Timer Range

user selectable from 5

minutes to 2 hours

Tachometer

not applicable

4-digit

LCD

Auto-Speed

standard

Power supply

HI 322N-1

110/115 Vac, 50/60 Hz

HI 322N-2

220/240 Vac, 50/60 Hz

HI 324N-1

110/115 Vac, 50/60 Hz

HI 324N-2

220/240 Vac, 50/60 Hz

Installation

Category

Cover

AISI 316 stainless steel

Material

Environment

0 to 50ºC (32 to 122ºF);

RH max 95%

Dimensions

180 x 180 x 70 mm

(7.1 x 7.1 x 2.8")

Weight

1.4 kg (3.1 lb.)

HI 322N & HI 324N
TIMER-CONTROLLED STIRRERS

HI 322N and HI 324N are autospeed stirrers
equipped with timer control to start and auto-
matically stop the stirring process after an
user-selectable period (from 5 minutes to
2 hours). They are the ideal stirrers for routine
applications where the required stirring time is
known, and for non-Newtonian fluids whose vis-
cosities change during stirring or Newtonian fluids
up to 5 liters capacity.

1. rpm LCD displays the rpm speed
2. Power indicator (LED lights up when the

stirrer is powered)

3. TIME knob for setting the stirring time

from 5 minutes to 2 hours

4. SPEED knob, to turn the stirrer ON and

OFF, and set the stirring speed (continu-
ously variable up to the maximum)

5. START/RESET switch for starting and re-

setting the time control

HI 324 TIMER CONTROL
MAGNETIC STIRRER

POWER

rpm

TIME

SPEED

5 min

OFF

2 hr

1.5 hr

0.5 hr

1 hr

MAX

START

RESET

HI 322 TIMER CONTROL
MAGNETIC STIRRER
